Features of the Bamberg Series 5 TM Monitor

• Minimalist TM design offers spacious imaging and an easy amplifier load
• Bass response optimized for integration with BESL subwoofers and for HT receivers´ 80Hz high-pass filter
• Tweeter offset from baffle centerline smoothes SPL response
• Reference Axis response optimized at 10 degrees off horizontal axis (tweeters to inside) and 6 degrees below vertical axis (to account for the 6 degree back-tilt of the cabinet)
• Thoroughly tested for QC

• 1" thick MDF baffle, fully cross-braced at driver hole webs
• Acoustic scallops in woofer hole interior edges smoothes low treble response
• 3/4" thick MDF wall panels with piano gloss black finish
• Interior cross bracing between opposing panels
• Sealed box alignment aids subwoofer integration
• 100% stuffed improves midrange clarity

• Externally housed passive network isolates the crossover from vibration and eliminates crosstalk between inductors and voice coils
• Speakon® 4-pole twist-lock connector guarantees tweeter protection and correct driver polarity with the outboard crossover
• External crossover facilitates easy upgrade to full active tri-amp. (Stereo tri-amp requires 6 amplifier channels and Speakon-terminated speaker cables.)
• Multi-strand solid core tweeter Umbilical cable connects monitor to outboard crossover
• 3-position switch provides "airy", "neutral", and "distant" treble contours
• Audiophile grade polypropylene capacitors and perfect-lay air-core inductors throughout
• Mills® tweeter series resistor
• "Passing Lane" cap bypasses main cap and series resistor in tweeter circuit for enhanced top octave "air"
• Optimized inductor/inductor orientation for reduced interaction
• No jumper wires; star grounding technique
• Reliable board fabrication and installation
• And of course, legendary BESL voicing!
